Qualitrol 104/TR6000 Capillary Based Oil Thermometer

Home >

Products and Solutions >

Temperature Measurement Devices >

Remote Mount Thermometers >

Qualitrol 104/TR6000 Capillary Based Oil Thermometer

Bourdon Tube Thermometer

Qualitrol 104 TR6000 capillary based transformer oil thermometer

m-l

Qualitrol 104 TR6000 capillary based transformer oil thermometer SCADA

m-l

Qualitrol 104 TR6000 capillary based transformer oil thermometer euro

m-l

Capillary based, remote indicating, mechanical thermometer. Features bourdon tube measurement with reset-able maximum pointer and up to 4 switches for temperature related alarms and control signals. Electronic outputs also available for integration into SCADA and remote monitoring systems.

Features

Bourdon tube based capillary measurement with reset-able maximum pointer
Up to 2 user adjustable switches (contacts) and one additional fixed switch for control and alarms
5 inch (130mm) dial face with an angular dial span of 120° for easy viewing
Low profile probe can be dressed for use in dry type transformers
Stainless steel bezel ring and probe resist corrosion
UV stabilized polycarbonate or glass lens options help prevent discoloration of dial face and lens for life-long readability
Available with up to 4 user-adjustable switches featuring lock down screws to reduce the effects of vibration and inhibit tampering

Options

Probe type and size, capillary length, protective armor and mounting styles can all be specified to meet your requirements
Models available for bearing temperature and dry-type transformer winding temperature applications
Optional SCADA analog outputs (0-1 mA and 4-20 mA) with integrated power supplies provide signals for remote monitoring and data acquisition
